A variant of the classic L4 reticle, the LR FD (15x) uses a more open outer post design to keep more of the target visible while aiming and offers extra aim points for holdover. The bright fibre optic center dot gives a sharp aim point for quick reference and target acquisition. The thick outer posts make visibility easy when hunting in low-light conditions. A fine upper post doesn't obstruct your view of the target.
SUBTENSIONS
The space between center dot and thick post measures 15" when aiming at a target 100yds away and on 15x magnification. This is equivalent to 50cm of spacing from center to post at 120m when on 15x magnification. Extra holdover aim points are included on the fine lower post to give graduation and accuracy when shooting at longer distances.
| |
| Optical System | System H7 |
| Scope Tube | 30mm |
| Magnification | 2.5-15x |
| Objective Lens | 50mm |
| Reticle | LR FD (15x) |
| Illumination | 11 |
| Parallax | Side Focus |
| Focal Plane | SFP (Second Focal Plane) |
| Lens Coating | Fully Multi-Coated - 21 Layers |
| Field of View | 45.3 - 7.5ft @ 100yds | 15.1 - 2.5m @ 100m |
| Field of View (°) | 8.6-1.4 |
| Eye Relief | 4in | 102mm |
| PX/Focus (Error free from) | 10yds - ∞ | 9m - ∞ |
| Exit Pupil | 0.79 - 0.13" |
20 - 3.3mm |
| Turret Type (Elevation) | Zero Lock 'n' Stop, Exposed, Locking, Resettable |
| Elevation Turret Clicks (max) | 100 MOA |
| Click Value | 1 ⁄ 4 MOA |
| Turret Type (Windage) | Exposed, Locking, Resettable |
| Windage Turret Clicks (max) | 110 MOA |
|
| Length | 14.8in | 375mm |
| Weight | 23.3oz | 660g |
| THIS SCOPE IS SUPPLIED WITH THE FOLLOWING |
![]() |
Instruction Manual |
|
|
Reticle Booklet |
Lens Cloth |
Pro Flip-Up Covers |
|
|
Zoom Lever |
Hex Key (Zoom Lever) |
CR2032 Battery |
|
|
|
4″ Sun Shade |
|
|
