Accurate mil spacing on 10x magnification. With half Mil spaced markings extending out to 10 Mil of holdover, the Mil Pro (10x) is a versatile reticle that provides aim points no matter how extreme the distance.
All reticle measurements are Mil spaced and offer 1 Mil, 0.5 Mil and 0.25 Mil brackets for range finding. Every second Mil spacing on the lower section is numbered to ensure quick and easy acquisition of target and ease of reference.
Each cross has a see-through gap, allowing an unobstructed view of the target. The thick outer posts are hollowed to ensure they can be seen at all magnifications, without blocking out too much of the view.
When on 10x magnification, the Mil spaced reticle and 1/10 MRAD turrets make for easy point of aim adjustment. Every 10 clicks on the turret will measure exactly 1 Mil spacing on the reticle, also known as 1 MRAD.
|
Optical System | System H7 |
Scope Tube | 30mm |
Magnification | 2.5-15x |
Objective Lens | 50mm |
Reticle | Mil Pro (10x) |
Illumination | 6 Levels with Off Positions In-between - Red |
Parallax | Side Focus |
Focal Plane | SFP (Second Focal Plane) |
Lens Coating | Fully Multi-Coated - 21 Layers |
Field of View | 45.3 - 7.5ft @ 100yds | 15.1 - 2.5m @ 100m |
Field of View (°) | 8.6-1.4 |
Eye Relief | 4in | 102mm |
PX/Focus | 10yds - ∞ | 9m - ∞ |
Exit Pupil | 0.79 - 0.13" | 2 - 3.3mm |
Turret Type | Zero Lock 'n' Stop |
Turret Caps | N/A |
Click Value | 1⁄ 10 MRAD |
Elevation Turret Clicks (max) | 32 MRAD |
Windage Turret Clicks (max) | 32 MRAD |
|
Length | 14.8in | 375mm |
Weight | 23.3oz | 660g |
THIS SCOPE IS SUPPLIED WITH THE FOLLOWING | Box |
Instruction Manual |
|
Reticle Booklet |
Lens Cloth |
Pro Flip-Up Covers |
|
Zoom Lever |
Hex Key (Zoom Lever) |
CR2032 Battery |
|
|
4″ Sun Shade |
|
|
