A variant on the classic L4 reticle, the 30/30 Duplex offers 30″ spacing from post to post at 100yds, when on 4x magnification
| |
| Optical System | System H2 |
| Scope Tube | 1 inch |
| Magnification | 2-7x |
| Objective Lens | 32mm |
| Reticle | 30/30 Duplex |
| Illumination | N/A |
| Parallax |
Fixed
|
| Focal Plane |
SFP (Second Focal Plane)
|
| Lens Coating |
Fully Multi-Coated - 11 Layers
|
| Field of View |
46.6 - 14.1ft @100yds
|
15.5 - 4.7m @100m
|
| Field of View (°) |
8.9 - 2.7
|
| Eye Relief | 3.5in | 90mm |
| PX/Focus | 100yds | 91m |
| Exit Pupil |
0.63 - 0.18″
|
16 - 4.6mm
|
| Turret Type | Capped |
| Turret Caps | Yes |
| Click Value | 1⁄ 4 MOA |
| Elevation Turret Clicks (max) |
140 MOA
|
| Windage Turret Clicks (max) |
140 MOA
|
|
| Length | 11.2in |
285mm
|
| Weight |
12.8oz
|
363g |
| THIS SCOPE IS SUPPLIED WITH THE FOLLOWING |
 |
Instruction Manual |
|
|
|
Lens Cover |
Lens Cloth |
|
|
|
|||
|
|
|
|
